      ECOSYS MZ3201ix

      The ECOSYS MZ3201ix helps organizations work smarter every day by delivering affordable access to enterprise-level capabilities, seamlessly connecting paper and digital workflows, and supporting modern print infrastructure with advanced security features.
      • 32ppm Black and White print, copy, scan, and optional fax
      • Up to 11 x 17, A3 size
      • Cloud-ready solutions simplify digital transformation
      • AI features boost scanning efficiency
      • Government-level security and modern authentication for securing sensitive data

      ECOSYS makes your office more sustainable and efficient

      Kyocera solutions always work with the environment in mind, but the ECOSYS range do this more than any other product on the market.

      Downloads

      • ECOSYS MZ3201ix Drivers
      • ECOSYS MZ3201ix Software

      Main Specifications

      General
      • General
      • Paper Handling
      • Print
      • Copy
      • Scan
      • Fax
      ECOSYS_MZ3201ix_main
      General type
      A3 B&W MFP (up to 11" x 17")
      Engine speed
      32 ppm b&w
      Warm-up time
      21.5 sec. or less
      Power consumption
      Printing/Copying: 490W in b&w and color, Ready mode: 70W, Low Power mode: 45W, Sleep mode: less than 0.3W
      Input capacity
      Single 500 sheet tray, 100 sheet MPT
      Max. input capacity with options
      1,600 sheets
      Duplex unit
      Standard stackless duplex supports statement (5.5" x 8.5") to ledger (11" x 17"), 16 lb Bond - 60 lb Cover (60 - 163 gsm)
      Max. output capacity
      Standard output tray 250 sheets + Job Separator tray 50 sheets
      Document processor
      Standard Reversing Automatic Document Processor: 50 sheets
      Processor
      ARM Cortex-A53 (Dual Core) / 1.4GHz
      Fonts

      93 Fonts PCL 6/KPDL3, 8 Windows, 1 Bitmap

      Applicable OS

      MAC OS X Version 10.9 or higher,Unix, Linux as well as other operating systems on request

      Max. original size
      11" x 17"
      Continuous copy
      1-999
      Zoom range
      25 - 400% in 1% Increments
      Preset magnification ratios
      5 Reductions/5 Enlargements
      Digital copy features
      Scan-once-copy-many, electronic sort, 2in1, 4in1, job reserve, priority print, program, auto duplex copy, split copy, continuous scan, auto cassette change (PF-470 or PF-471 is required), copy density control, Prevent Bleed-Through, ID card copy, Skip blank page
      Scan functionalities
      Scan-to-email, Scan-to-FTP, Scan-to-SMB, Scan to USB Host, Network TWAIN, WIA, WSD scan
      Scan speed
      50 ipm simplex / 16 ipm duplex
      Scan resolution
      1200 x 1200 dpi (TWAIN/WIA Driver), 600 x 600 dpi, 400 x 400 dpi, 300 x 300 dpi, 200 x 400 dpi, 200 x 200 dpi, 200 x 100 dpi
      Max. scan size
      11" x 17"
      File type
      TIFF, PDF, PDF/A, JPEG, Open XPS, Encrypted PDF, High compression PDF, PDF/A-1a/b, PDF/A-2a/b/u
      Compatibility
      G3 Fax
      Modem speed
      33.6 Kbps
      Transmission speed
      Less than 3 seconds
      Max. original size
      11" x 17"
      Fax features
      Network fax, duplex transmission and reception, encrypted transmission and reception, polling transmission and reception, broadcast

      Options and Consumables

      Paper Handling Options
      • Paper Handling Options
      • Options
      Card Authentication Kit (B)

      Support for various proximity card readers
      Fax System 14
      G3 Fax, Network FAX Driver
      IB-37
      Wireless LAN Interface (802.11 a/b/g/n/ac, 5 GHz band / 2.4 GHz band, Wi-Fi direct)
      IB-38
      Wireless LAN Interface (802.11 b/g/n, 2.4 GHz band, Wi-Fi direct)
      IB-53

      Gigabit Ethernet Board for Dual NIC
      IB-54
      Wireless LAN 5GHz/2.4GHz
      IB-55
      Wireless LAN 2.4GHz only
      Scan Extension Kit (A)

      Scan to searchable PDF (embedded OCR) or to MS Office (docx, xlsx, pptx)
      UG-33

      Thin Print support
      • ECOSYS_MZ3201ix_PR
      • ECOSYS_MZ3201ix_01_L
      • ECOSYS_MZ3201ix_02_R
      • ECOSYS_MZ3201ix_03_R
      • ECOSYS_MZ3201ix_07_F
      • ECOSYS_MZ3201ix_Panel_15
